SURFACE DERIVATION WATERPROOF BOX 180X241X95 HALOGEN FREE EV231IDE p>
SEALED BOX DERIVATION EV 231 IDE.
- Free box halogens.
- With cable glands.
- Dimensions: 180x241x95mm.
- Cable entry: 4 M25, 6 M40 p>
- Degree of protection IP54
- Impact resistance IK07
- Degree of self-extinguishing HB (UL94).
- Resistance to 650C incandescent wire.
- Ball pressure 70C.
- Ambient temprature range -25C / + 40C.
General characteristics:
The Light bypass sealed boxes are sealable and made of phallus-free material. They feature 25 and 40mm cable glands in the EV versions, halogen-free cones in the EV / LH versions, as well as petroleum-lined cable entries in the EX versions and smooth laterals in the EL versions.
They have pliant locking screws (1/4 turn) and safety pins, and screws with arp termination for fixing the base cover
