THEBEN TR610-TOP2 DIGITAL TIME SWITCH

THEBEN TR610-TOP2 DIGITAL TIME SWITCH. 16A 1CANAL

Function description

• Digital time switches with weekly schedule
• Special device with special relay (gold contact) for switching small loads
• 1 channel
• Quick terminals
• For 2 drivers each
• Cable or wire (with or without wire ferrule)
• Cable diameter: 0.5 - 2.5 mm²
• Control button for unplugging the plug connection
• Use guide in the form of text on the screen
• Preconfigured date and time
• Total manageability without connection to the network
• 56 programming memories
• Interface for the OBELISK top2 memory card (PC programming)
• 2nd plug-in switching program
• Copy of programs
• Program recording
• 10-year power reserve (lithium battery)
• Zero-pass switching for relay protection and for switching high lighting powers (not available in 24 V products)
• CONNECTION / DISCONNECTION times
• Connection preselection
• Permanent connection ON / OFF
• Integrated hour meter
• Possible replacement to the initial state
• Maintenance function for the control of maintenance intervals
• Program of vacations programmable by date
• Screen lighting (disconnectable)
• PIN code
• Automatic change of summer / winter time
• deactivatable
• Switching rules predefined for Europe, USA UU and other countries
• Possibility of selecting a switching rule propia or switching on a fixed date
